Description
The Bitmain ANTRACK V2 is a compact 24 kW Hydro cooling and heat-recovery system designed for professional, commercial and advanced small-scale mining installations. It supports up to 4 Antminer Hydro miners, 4 U2 Hydro miners or 2 U3 Hydro miners, combining liquid cooling, centralized infrastructure and useful heat recovery in a single modular platform. The system can transfer mining heat into compatible hydronic applications such as space heating, domestic hot water, greenhouses or pools. Next Level Corp provides local sales, deployment guidance and long-term technical support.
| Manufacturer | Bitmain |
|---|---|
| Model | ANTRACK V2-EC4-DTHP |
| Product type | Hydro cooling and heat-recovery system |
| Installed capacity | Up to 4 × Antminer Hydro, 4 × Antminer U2 Hydro or 2 × Antminer U3 Hydro |
| Heat dissipation capacity | 24 kW |
| Cooling | Closed-loop Hydro cooling with external heat-recovery cooler |
| Electrical input | 380–415 V AC |
| Input current | 63 A |
| Pump rated power | 450 W |
| Pump noise | Approximately 60 dBA @ 1 m |
| Pump lift | 19 m |
| Water pipe connector | DN20 |
| Main unit dimensions | 1200 × 600 × 1300 mm |
| Main unit packaged dimensions | 1460 × 780 × 1330 mm |
| Listed main unit weight | Approximately 210 kg |
| External cooler dimensions | 1340 × 570 × 1330 mm |
| External cooler packaged dimensions | 1490 × 590 × 1495 mm |
| External cooler net / gross weight | 235 kg / 248 kg |
| External cooler electrical input | 380–415 V AC · 50–60 Hz |
| External cooler max input current | 21 A |
| Heating capacity | Approximately 32 kW typical |
| Compressor input | Approximately 8 kW typical |
| EER | Approximately 3.0 |
| External cooler noise | Approximately 50 dB(A) |
| Refrigerant | R290 |
| Heating water outlet temperature | Up to approximately 80 °C |
Notes
- The ANTRACK V2 requires a professional 380–415 V electrical installation suitable for the configured Hydro mining equipment and cooling infrastructure.
- The system supports up to four standard Hydro/U2 Hydro miners or two U3 Hydro miners, depending on the physical format and power requirements of the installed equipment.
- Recovered mining heat can be reused in compatible hydronic systems such as building heating, domestic hot water, greenhouses, pools or similar thermal applications.
- Actual heat recovery depends on mining load, coolant temperatures, ambient conditions and the thermal demand of the connected facility.
- Verify electrical distribution, protection devices, grounding, plumbing, installation clearances and miner compatibility before deployment.
- Two freight options are available: Air Freight with an estimated 7-day delivery time and Sea Freight with an estimated 45-day delivery time.
Your purchase includes (Next Level Corp)
- Pre-installation compatibility and deployment guidance.
- Guidance for electrical and Hydro cooling installation requirements.
- Configuration assistance for compatible Hydro mining equipment.
- Guidance for integration with compatible heat-recovery applications.
- Remote technical assistance during setup and commissioning.
- Pool and wallet configuration assistance for installed miners.
- Lifetime 24/7 technical advice.
- Genuine spare parts and compatible Hydro accessories available for sale.
- Local service and technical support in Bolivia.
- Manufacturer warranty according to the applicable equipment and purchase terms.
This product is available with two freight options: Air Freight or Sea Freight. Select the preferred shipping option above to display the corresponding price and estimated delivery time.
Important Notice:
The ANTRACK V2 is specialized Hydro mining and heat-recovery infrastructure and requires appropriate electrical capacity, liquid-cooling connections, installation space and professional commissioning. The 24 kW specification refers to the system’s heat-dissipation capacity and should not be interpreted as the hashrate or standalone power consumption of an ASIC miner. Final site and miner compatibility should be confirmed before installation.
Tags: ANTRACK, ANTRACK V2, Bitmain ANTRACK, Hydro, Hydro Mining, Minería Hydro, 24 kW, Heat Recovery, Recuperación de calor, Hydro Cooling, Refrigeración líquida, Sistema de refrigeración líquida para minería, Antminer Hydro, Antminer U2 Hydro, Antminer U3 Hydro, Mining Cooling, Enfriamiento de minería, R290, Calefacción, Agua caliente.
